Cummins generating set 1100kw 1375kva

Power Standards


The engine performance corresponds to ISO 3046, BS 5514 and DIN 6271. The technical data applies to an engine without cooling fan and operating on a fuel with calorific value of 42.7 MJ /kg (18360 BTU/lb) and a density of 0.84 kg/liter (7.01 lb/US gal), also where this involves a deviation from the standards. Power output guaranteed within 0 to +2% att rated ambient conditions at delivery. Ratings are based on ISO 8528. Engine speed governing in accordance with ISO 3046/IV, class A1 and ISO 8528-5 class G3 Exhaust emissions The engine complies with Tier 2 and TA-luft exhaust emission regulations.

Unit Type	KTA50-G8
Power	1500KVA/1200KW
Engine Model	KTA50-G8
CyI.	4L
Bore/stroke(mm)	108/130
Fuel consumption(g/kwh)	213

Genset Technical Data
Genset Model	AI-1500
Rated Voltage	110-600V(Can be adjusted)
Rated Frequency	50HZ
P.F(COS)	0.8
Prime Power	1100KW
Standby Power	1210KW



Cummins Engine Data
Engine Model	KTA50-G8
Number of Cylinders	12
Aspiration	Turbocharged
Bore×Stroke	159mm x159mm
Displacement	50.3L
Prime Power/Speed	1200KW / 1500rpm
Standby Power/Speed	1320KW / 1500rpm
Speed Governor	Electrical
Cooling System	Forced water cooling cycle



Alternator Data
Optional brands	Stamford/Leroy Somer/Marathon
Prime power	1000KW
Frequency/speed	50Hz/1500rpm
Exciter type	Brushless, Self-excited
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation Grade	H
Protection Grade	IP23



1. Who are we?

We are based in Xiamen, China, sell to Domestic Market(10.00%),South Asia(10.00%),Central
America(10.00%),Eastern Asia(10.00%), Mid East(10.00%), Oceania(10.00%), Africa(10.00%), Southeast Asia(10.00%), North America(10.00%). There are total about 101-200 people in our factory.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
Generator set, Diesel generator set, Generator, Cumins generator, Perkins Generator, Volvo generator.
